EXODUS – Pulse High Power Amplifiers
 Header.jpg)
Exodus Advanced Communications Pulse High Power Block Up Converter (BUC) from 1MHz to 12GHz
Exodus Pulse SSPA (Solid State Power Amplifiers) products feature LDMOS, GaN discrete, and Chip & Wire technologies covering frequency ranges from 1MHz to 12GHz at power levels exceeding 1KW for Modules and 10KW for Systems.
|
SYSTEM MODELS |
MIN |
MAX |
OUTPUT |
GAIN |
SOURCE |
DATA |
| AMP2013P |
20 |
500 |
600 |
58 |
100-240 |
|
| AMP2052P |
30 |
520 |
1000 |
60 |
180-240 |
|
| AMP2052P-1 |
30 |
120 |
1000 |
60 |
187-265 |
|
| AMP4040P |
120 |
200 |
4000 |
66 |
208 |
|
| AMP2052P-2 |
120 |
610 |
1000 |
60 |
187-265 |
|
| AMP2132P |
150 |
3400 |
10000 |
75 |
48 |
|
| AMP4061P |
150 |
225 |
10000 |
70 |
208 |
|
| AMP4028P-1-2-4 |
184 |
214 |
2000 |
60 |
100-240 |
|
| AMP4044P |
320 |
420 |
400 |
50 |
100-240 |
|
| AMP6041P |
437 |
431 |
6300 |
68 |
100-240 |
|
| AMP2086BP |
500 |
3000 |
200 |
53 |
100-240 |
|
| AMP2131P |
500 |
1000 |
10000 |
70 |
208 |
|
| AMP4050P |
950 |
1250 |
350 |
57 |
180-240 |
|
| AMP4056P |
950 |
1250 |
4000 |
65 |
120-240 |
|
| AMP4016P |
1000 |
1200 |
10000 |
60 |
220 |
|
| AMP2043P-4K |
1000 |
2000 |
4000 |
66 |
100-240 |
|
| AMP6026P |
1000 |
1000 |
5000 |
67 |
100-240 |
|
| AMP2131-2P |
1000 |
2000 |
10000 |
70 |
208 |
|
| AMP2043P-05K |
1000 |
2000 |
500 |
60 |
100-240 |
|
| AMP2131-1P |
1000 |
2000 |
8000 |
69 |
208 |
|
| AMP6003P |
1059 |
1059 |
1000 |
60 |
100-260 |
|
| AMP6009P |
1575 |
1575 |
2000 |
63 |
100-240 |
|
| AMP2073-1P |
2000 |
12000 |
15 |
42 |
100-240 |
|
| AMP2136P-2KW |
2000 |
4000 |
2000 |
63 |
180-240 |
|
| AMP4003P |
2700 |
3000 |
10000 |
53 |
380/220 |
|
| AMP4025P |
2700 |
3100 |
300 |
18 |
100-240 |
|
| AMP4003P-1 |
2700 |
2900 |
8000 |
69 |
380/220 |
|
| AMP4025P-1 |
2700 |
3100 |
1000 |
23 |
100-240 |
|
| AMP4038P |
2700 |
2900 |
10000 |
70 |
220 |
|
| AMP4025P-2 |
2900 |
3100 |
1700 |
62 |
100-240 |
|
| MODEL |
MIN FREQUENCY |
MAX FREQUENCY |
OUTPUT |
GAIN |
Source |
DATA SHEETS |
|---|---|---|---|---|---|---|
| AMP4025P-3 |
2990 |
3010 |
400 |
56 |
100-240 |
|
| AMP4001P-1 |
3000 |
3500 |
750 |
58 |
180-240 |
|
| AMP4001P |
3100 |
3500 |
1300 |
38 |
180-260 |
|
| AMP2083P-5KW |
4000 |
8000 |
5000 |
67 |
180-260 |
|
| AMP2083P-2KW |
4000 |
8000 |
2000 |
63 |
180-240 |
|
| AMP4057P |
8500 |
10500 |
200 |
53 |
100-240 |
|
| AMP4060P |
9000 |
9900 |
8000 |
69 |
115 |
|
| AMP4002P |
9100 |
9500 |
500 |
58 |
230 |
|
| AMP4060P-1 |
9200 |
10000 |
8000 |
60 |
|
|
| AMP6020P-1000 |
9200 |
9500 |
1000 |
60 |
208 |
|
| AMP4015P |
9300 |
9500 |
8000 |
69 |
115 |
|
| AMP4057-1P |
9300 |
9800 |
200 |
50 |
100-240 |
|
| AMP4057P-1 |
9300 |
9800 |
200 |
50 |
100-240 |
|
| AMP6020P-400-800 |
9600 |
9900 |
400-800 |
5X |
230 |
|
| AMP6020P-200-300-500 |
9600 |
9900 |
200 |
53 |
230 |
|
| AMP6035P |
9700 |
9900 |
4000 |
66 |
180-260 |
|
| AMP6022P |
11424 |
11424 |
500 |
57 |
100-240 |
|
| AMP4053P |
12800 |
14000 |
28 |
40 |
100-240 |
|
| AMP6031P |
15400 |
15700 |
2000 |
63 |
230 |
|
