innco systems Reaction Time Test Device
The Reaction Time Test Device RTG-IV is a microcomputer time measuring device that works with a very high level of precision. The device has a randomizer that ensure a surprise effect during the testing process. The random time range is between 2 and 8 seconds. It measure the time between when the red signal lamp lights up (possibly with a signal sound) and when the subject presses the brake pedal. The microcomputer than uses the set speed and road condition to calculate:

– The reaction Time
– The braking distance
– The stopping distance

The speed and road condition are displayed along with reaction time. The set values and the test results are printed on a paper strip using an built in printing device.

Eight speed levels can be set, whereby a test for reaction time only must be carried out with the setting «o km/h». The icons «Sun», «Cloud», «Ice» can set various road conditions.

As well as speed and the road condition, there is also a brake response time and a brake effect time included in the calculation for the braking distance.

Furthermore, the output of the test result on the printout is made dependent on the selected test parameters.

 innco systems Reaction Time Test Device Data Sheet
