CDN - Coupling / Decoupling Networks
The Coupling- / Decoupling Networks are used to inject common mode disturbances to Equipment under Test (EUT). Further the CDNs provide sufficient decoupling between Auxiliary Equipment (AE) and disturbance signal. The requirements for CDN and their application are described in the standard IEC 61000-4-6 (Immunity to conducted disturbances, induced by radio-frequency fields). CDNs have a common mode impedance of 150 Ohm and are available for a multitude of cable types and connectors.
Schwarzbeck CDN Overview and Selection Guide Data Sheet
CDN QUICK – SECTION GUIDE
|
Cable type |
CDN type |
Application |
Product range |
|
|
|
||
|
|
|
CDN AF2
|
|
|
|
|
|
CDN S1
|
|
|
|
|
|
CDN M-TYPE – MAINS / POWER SUPPLY APPLICATIONS
|
CDN Dimensions |
Length L1 |
Length L2
|
Width W
|
Height H
|
Case A
|
225 mm |
216 mm |
105 mm |
108 mm |
Case B
|
305 mm |
266 mm |
105 mm |
107 mm |
Case C
|
290 mm |
251 mm |
165 mm |
167 mm |
Case D
|
– |
107 mm |
105 mm |
48 mm |
|
|
AE Port |
EUT Port |
Frequency Range |
EUT/AE connection type |
Max. Current Value |
Input Voltage EUT |
Case Size |
|
|
|
0.15…230 MHz |
4 mm safety |
16 A |
500 VAC |
A |
|
|
|
|
0.15…230 MHz |
4 mm safety |
16A |
500 VAC |
A |
|
|
|
|
0.15…230 MHz |
4 mm safety |
32 A |
500 VAC |
B |
|
|
|
|
0.15…230 MHz |
Multi-Contact |
63 A |
500 VAC |
C |
|
|
CDN M2 125A 1000V |
|
|
0.15…230 MHz |
Multi-Contact |
125 A |
500 VAC |
C |
|
|
|
0.15…230 MHz |
4 mm safety |
16 A |
250 VAC |
A |
|
|
CDN M3PE 16A 1000V |
|
|
0.15…230 MHz |
4 mm safety |
16 A |
250 VAC |
A |
|
|
|
0.15…230 MHz |
4 mm safety |
32 A |
500 VAC |
A |
|
|
|
|
0.15…230 MHz |
4 mm safety |
32 A |
500 VAC |
A |
|
|
CDN M3PE 125A 1000V |
 |
 |
0.15…230 MHz |
4 mm safety |
32 A |
500 VAC 1000 VDC |
A |
|
|
|
0.15…230 MHz |
4 mm safety |
16 A |
500 VAC |
A |
|
|
|
|
0.15…230 MHz |
4 mm safety |
16 A |
500 VAC |
A |
|
|
|
|
0.15…230 MHz |
4 mm safety |
32 A |
500 VAC |
B |
|
|
|
|
0.15…230 MHz |
4 mm safety |
32 A |
500 VAC |
B |
|
|
|
|
0.15…230 MHz |
4 mm safety |
63 A |
500 VAC |
B |
|
|
CDN M4PE 125A 1000V |
|
|
0.15…230 MHz |
4 mm safety |
125 A |
500 VAC |
B |
|
|
|
0.15…230 MHz |
4 mm safety |
16 A |
500 VAC |
B |
|
|
CDN M5PE 32A 1000V |
|
|
0.15…230 MHz |
4 mm safety |
32 A |
500 VAC |
B |
|
|
|
0.15…80 MHz |
Multi-Contact |
63 A |
500 VAC |
C |
|
|
CDN M5PE 125A 1000V |
|
|
0.15…80 MHz |
Multi-Contact |
125 A |
500 VAC |
C |
SCHWARZBECK CDN AF-TYPE-UNSCREENE UNBALANCED LINES
AE Port |
EUT Port |
Frequency Range |
EUT/AE connection type |
Max. Current Value |
Input Voltage EUT |
Case Size |
|
|
|
|
0.15…230 MHz |
4 mm safety |
4 A (DC) |
100 VAC |
A |
|
|
|
|
0.15…230 MHz |
4 mm safety |
4 A (DC) |
100 VAC |
A |
|
|
|
|
0.15…230 MHz |
4 mm safety |
4 A (DC) |
100 VAC |
A |
|
|
|
|
0.15…230 MHz |
4 mm safety |
4 A (DC) |
100 VAC |
A |
|
|
|
|
0.15…230 MHz |
4 mm safety |
4 A (DC) |
100 VAC |
A |
SCHWARZBECK CDN S-TYPE-SCREENED CABLES
Product |
Drawing |
Frequency range |
EUT/AE
|
Case size |
|
AE Port |
EUT Port |
||||
CDN S1 BNC |
|
|
0.01…230 MHz |
1x BNC 50 Ω |
A |
CDN S1 BNC 75 |
|
|
0.01…230 MHz |
1x BNC 75 Ω |
A |
CDN S2 XLR3-1 |
|
|
0.01…230 MHz |
XLR3-1
|
A |
CDN S2 XLR3-3 |
|
|
0.01…230 MHz |
XLR3-3
|
A |
CDN S4 4xBNC
|
|
|
0.01…230 MHz |
4x BNC 50 Ω |
A |
CDN S4 XLR4
|
|
|
0.01…230 MHz |
XLR4 female |
A |
CDN S4 DIN5-1 |
|
|
0.01…230 MHz |
DIN5 GND:PIN1 |
A |
CDN S8 RJ45 |
|
|
0.01…230 MHz |
RJ45 |
A |
CDN S9 SUBD |
|
|
0.01…230 MHz |
Sub-D 9 pol. |
B |
CDN S9 USB3.0 |
|
|
0.15…230 MHz |
USB 3.0 |
B |
CDN S15 VGA |
|
|
0.01…230 MHz |
VGA |
B |
CDN S19 HDMI |
|
|
0.01…230 MHz |
HDMI |
B |
CDN S24 USB-C |
|
|
0.15…230 MHz |
USB-C |
A |
CDN S25 SUBD |
|
|
0.15…230 MHz |
Sub-D 25 pol. |
B |
SCHWARZBECK CDN T-TYPE-UNSCREENED BALANCED LINES
Product |
Drawing |
Frequency range |
EUT/AE
|
Max. Current rating |
Case size |
|
AE Port |
EUT Port |
|||||
CDN T2 |
|
|
0.01…230 MHz |
4 mm safety
|
0.25 A |
A |
CDN T4
|
|
|
0.01…230 MHz |
4 mm safety
|
0.25 A |
A |
CDN T4 RJ45
|
|
|
0.15…230 MHz |
RJ 45 |
0.25 A |
D |
DN T8 RJ45 |
|
|
0.15…230 MHz |
RJ 45 |
0.25 A |
D |
SCHWARZBECK 10 KHZ CDN
Product |
Description |
|
Schwarzbeck Coupling Decoupling Network for IEC 61000-4-6, type M2, 16 A, 1000V, 10 kHz-80 MHz (banana), L1, L2, including 2 pieces of short adapters for AE and DuT side CA 2/4 and traceable calibration (certificate according ISO17025) for IEC 61000-4-6. |
|
|
CDN10 M3 125A 1000V |
Schwarzbeck Coupling Decoupling Network for IEC 61000-4-6, type M3, 125 A, 1000V, 10 kHz-230 MHz (banana), L1,L2,N or L1,L2,L3 including 2 pieces of short adapters for AE and DuT side CA 3/4 and traceable calibration (certificate according ISO17025) for IEC 61000-4-6. |
A-TYPE CDN FOR COAXIAL ANTENNA INPUTS CNA 280
· The CNA280 meets the specifications of the standard CISPR 16-1-2 A1, figure C1 (unit type A) and CISPR 16-1-3, app. B,Fig. 9.
· It is also required to calibrate EMI absorbing clamps like the MDS 21.
